Item # | 927817 |
Manufacturer # | 2738677 |
80 PLUS Certification | 80 PLUS Gold |
ATI CrossFire Supported | Yes |
brand name | Thermaltake |
color | Black |
Compatibility | Quad Core Processors:Intel; AMD |
depth | 7.1 in. |
Efficiency | 93% |
ENERGY STAR | Yes |
Environmental Certification | RoHS; WEEE; 80 Plus Gold; ENERGY STAR |
form factor | Internal |
Input Connectors | 1 |
Input Current | 10 A @ 110V; 5 A @ 220V |
Input Voltage | 110 V AC; 220 V AC |
Input Voltage Range | 90 V AC to 264 V AC |
Input Voltage Type | AC |
manufacturer | Thermaltake Technology Co., Ltd |
model | TPG-750M |
MTBF | 120,000 Hour |
Number of +12V Rails | 1 |
number of fans | 1 |
NVIDIA SLI Supported | Yes |
Output Current | +5V - 25 A ¦ +3.3V - 25 A ¦ +12V - 60 A ¦ -12V - 0.8 A ¦ +5VSB - 3 A |
Output Power | 750 W |
Output Voltage | 3.3 V DC @ 25 A; 5 V DC @ 25 A; 12 V DC @ 60 A; -12 V DC @ 800 mA; 5 V DC @ 3 A |
Plug/Connector | On/Off Switch |
Power Factor Correction (PFC) | Active |
Product Line | Toughpower |
Product Series | Grand |
protection type | Over Current; Over Power; Over Voltage; Under Voltage; Short Circuit; Overload; Over Temperature |
Receptacles | 1 x 24-pin ATX Motherboard; 1 x 4+4pin ATX12V Motherboard; 1 x 8-pin EPS12V Motherboard; 2 x 6-pin PCI-E; 2 x 6+2pin PCI-E; 1 x 4-pin SP4 Floppy Drive; 8 x Serial ATA; 8 x 4-pin LP4 Peripheral Device |
Specification Compliance | ATX12V/EPS12V |
warranty length | 7-year limited |
